Axiom Vault Metal Consumer Unit 18 Way with 100A Main Switch
PRODUCT SUMMARY
VAULT by AXIOM is the next generation in circuit protection, combining premium safety, durability and installer-focused design. Built for residential, commercial and light industrial applications, VAULT units feature fire-resistant steel construction, large terminals, an integrated spirit level, dual-screw isolators and generous wiring space for easier, faster installation. Supplied with a 100A DP isolator and robust accessories including MCB blanks, grommet strip and magnetic door holder.
TECHNICAL SPECIFICATION
| Number of Ways | 18 (16 free ways) |
| Isolator | 100A DP Main Switch |
| Current | 100A |
| Body Material | Steel, White |
| Dimensions (mm) | 388 x 270 x 123 |
| Knockouts | 1 x 20, 2 x 25, 2 x 32, 2 x 40 |
| Compliance | BS EN 61439-3, CE, UKCA |
| Ingress Protection | IP20 |
| Input Voltage | 220-240V |
| Mounting | Wall |
| Warranty | 1 Year |
